The Synergy 1994-2013 Dodge Ram 1500 / 2500 / 3500 HD Adjustable Track Bar is designed to increase the strength between the frame and axle and is fully adjustable to help center the axle underneath your truck. It can adjusted from 38.625" (.25" shorter than stock) to 39.438". This allows the track bar to be used when lowering trucks for truck pull & race applications (up to 3" lower than factory height) and lifted applications up to 6.0" over factory height for off road use. The bar is bent to clear most aftermarket differential covers and uses maintenance free Synergy Dual Durometer bushings on both ends.
Fitment:
- 1994 - 2002 Dodge Ram 1500 / 2500 / 3500 with use of Synergy Part 8554-02
- 2006-2008 Dodge Ram 1500 Megacab 4x4
- 2003-2013 Dodge Ram 2500 4x4
- 2003-2013.5 Dodge Ram 3500 4x4
- Warning: 2013 Dodge Ram 3500's were a split year for production. If your truck has radius arms use part number 8704-01.
Benefits:
- Allows centering of front axle when running a suspension lift
- Increased Strength from Stock
- Adjustable without removing from vehicle
- Maintenance Free, no greasing required
- Synergy Dual Durometer Bushings eliminate binding issues associated with stock vulcanized bushings
- No jam nuts that are impossible to keep tight
- No modifications required to install
- Isolates Noise, Vibration, and Harshness (NVH) increasing ride quality
- Bent to clear most aftermarket differential covers with no additional lift height required
- Limited Lifetime Warranty
Features:
- Made from high quality 1.5" x .250" wall DOM tubing
- Bent to clear most aftermarket differential covers
- Retains factory track bar mounting bolts & hardware
- Suspension components feature an abrasion-resistant powder coat finish for maximum durability and corrosion resistance
- Synergy double adjuster sleeve & pinch bolt assembly allows for adjustment of track bar length without removing control arm mounting bolt
- Features Synergy Dual Durometer Bushings (DDB) with Teflon® bearing surface for a maintenance free design focusing on performance, flex, longevity, and ride quality
- 100% bolt on components assures an easy, trouble free installation with the use of basic hand tools
Min/Max Length:
Measured in straight line from center of bolt hole to center of bolt hole
- Min collapsed length: 38.625"
- Max extended length: 39.438"
Includes:
- (1) Synergy Dodge Front Track Bar
- (1) Grade 8 Hardware Kit
- (1) Synergy Double Adjuster Sleeve
Notes:
- 8550-11 Replacement Parts (Bars Built after 1/1/2021)
- 8550-01 Replacement Parts (Bars built 5/19/2015 - 1/1/2021)
- 8550-01 Replacement Parts (Bars built before 5/19/2015)
*If you have any trouble identifying your track bar please contact our Support Team Here
